Product & customer support

When you buy one of our IoT products, we charge a flat rate for domestic shipping (within the continental US) for 2-day air. International Shipping is calculated on a per country basis.

Sales tax is calculated by the shipping address entered. International shipping may include tariffs or other applicable taxes. We will need a tax-exemption certificate, if applicable.

We accept e-checks, wire transfers, and credit cards. A fee will be added for credit card payments.

We use custom packaging that has been tested for properly cushioning our products. We use 2-day air (FedEx or UPS) for domestic shipping.

We usually ship out an order within 24 hours of order receipt. However, we occasionally have inventory shortages. Inventory amounts should be available during the ordering process

Please contact us at support@spanalytics.com and we will get you a RMA number.

• Size: 3.5” x 3.0” x 0.8” (90mm x 78mm x 20mm)
• Weight: 0.25 lbs. (110g)
• Power: 4.5W max, powered via single USB3 port
• Frequency Range: 2400 – 2483.5 MHz
• Timing accuracy: 250 ns
• Clock accuracy: +- 0.28 ppm over temperature range
• Operating Temperature: 32°F to 113°F (0°C to 45°C)
• Humidity Rating: 0% to 90% (non-condensing)
• On-board SD Card: 4GB Capture capacity
• Device Input / Output: Antenna – standard SMA female, Sync connectors – MMCX, Logic analyzer – Hirose LX40P, Multi-color LED indicator
• Protocols: Bluetooth Classic (BR/EDR) and Bluetooth Low Energy, compliant to Core version 5.1
• Operating Systems: Windows, MacOS, and Linux

Any PC that can run the above operating systems is suitable for operating the PANalyzr. The PC will need a USB3 port. The more RAM, the better for buffer management ( > 4GB).

Please contact us and we will send you a link to our shared drive.

• Data export to analytics packages
• Support for our new FindIT product
• LoRa/LoRaWAN capture with our IoT Expansion Pack
• Improvements to our decryption utility (brackle)

• The hardware or software is in a bad state; disconnect and reconnect the hardware, then restart the software.
• The threshold is set too high, this is a setting that can be changed from the Windows GUI or command line option for the other OS’s.
• Do you have filters set in Wireshark that might be preventing packets from being displayed?
• The test devices are too far or too at too low a tx/rx level. Can you move closer?
• The duty cycle for the communication between the test devices is low or sporadic. This might be a timing issue (making sure to capture at the right time) or trying to increase the amount of traffic on the network.

There are several options. To reduce traffic at the front-end, try raising the packet RSSI threshold value. The higher the value (less negative), the fewer packets you will see. However, keep in mind that you will not see packets below the threshold and with a Bluetooth device using power management, it can be hard to predict its power levels. Or, you may want to physically segregate your test area from unwanted traffic; find a “quiet” space to do the captures or use an RF shielding technique like an RF blanket or Ramsey Box. You can reduce traffic in Wireshark by applying filters. Please see the Wireshark documentation on how to do this.
